5V cooling fan

DC5V DC cooling fan - copy - copy - copy - copy - copy

  • model:DC2510
  • Size: 25×25×10mm
  • Bearing: Two Ball & Sleeve (Sleeve or Long Life Sleeve)
  • Safety: CE approved, RoHS
  • Product description: DC5V DC cooling fan
  • INQUIRY

Available Functions

Available Functions






Motors protection(保护功能) Signal output(输出功能) Speed control(调速功能)
RP AS CS CL OV SS FG RD/RDb LD PPWM VPWM TC RC
反接保护 锁定保护 恒速保护 限流保护 过压保护 软启动 转速侦测 停转告警 设定告警 占控比调速 电压调速 温控调速 电阻调速


Specifications

Specifications






Model Rated Voltage (VDC) Operating Voltage (VDC) Current Power Speed Max. Air Flow Max.Static Pressure Noise
(AMP) (WATTS) (RPM) (CFM) (m³/min) (mm-H2O) (pa) (dBA)
规格型号 额定电压 操作电压 工作电流 输入功率 转速 风量 风压 噪声
BDB(S)2510H05 5 4~6 0.25 1.25 12000 2.11 0.06 5.68 55.70 29.50
BDB(S)2510M05 5 4~6 0.16 0.80 10000 1.60 0.05 3.95 38.74 23.20
BDB(S)2510L05 5 4~6 0.14 0.70 7000 1.22 0.03 1.97 19.32 21.50
BDB(S)2510H12 12 6~13.8 0.12 1.44 12000 2.11 0.06 5.68 55.70 29.50
BDB(S)2510M12 12 6~13.8 0.09 1.08 10000 1.60 0.05 3.95 38.74 23.20
BDB(S)2510L12 12 6~13.8 0.05 0.60 7000 1.22 0.03 1.97 19.32 21.50
