220V cooling fan

  • DC5V DC cooling fan - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy
  • DC5V DC cooling fan - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy
  • DC5V DC cooling fan - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy
DC5V DC cooling fan - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copyDC5V DC cooling fan - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copyDC5V DC cooling fan - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy

DC5V DC cooling fan - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy - copy

  • model:DC2510
  • Size: 25×25×10mm
  • Bearing: Two Ball & Sleeve (Sleeve or Long Life Sleeve)
  • Safety: CE approved, RoHS
  • Product description: DC5V DC cooling fan
  • INQUIRY

Available Functions

Available Functions






Motors protection（保护功能） Signal output（输出功能） Speed control（调速功能）
RP AS CS CL OV SS FG RD/RDb LD PPWM VPWM TC RC
反接保护 锁定保护 恒速保护 限流保护 过压保护 软启动 转速侦测 停转告警 设定告警 占控比调速 电压调速 温控调速 电阻调速
● ● ● ●


Specifications

Specifications






Model Rated Voltage (VDC) Operating Voltage (VDC) Current Power Speed Max. Air Flow Max.Static Pressure Noise
(AMP) (WATTS) (RPM) (CFM) (m³/min) (mm-H2O) (pa) (dBA)
规格型号 额定电压 操作电压 工作电流 输入功率 转速 风量 风压 噪声
BDB(S)2510H05 5 4~6 0.25 1.25 12000 2.11 0.06 5.68 55.70 29.50
BDB(S)2510M05 5 4~6 0.16 0.80 10000 1.60 0.05 3.95 38.74 23.20
BDB(S)2510L05 5 4~6 0.14 0.70 7000 1.22 0.03 1.97 19.32 21.50
BDB(S)2510H12 12 6~13.8 0.12 1.44 12000 2.11 0.06 5.68 55.70 29.50
BDB(S)2510M12 12 6~13.8 0.09 1.08 10000 1.60 0.05 3.95 38.74 23.20
BDB(S)2510L12 12 6~13.8 0.05 0.60 7000 1.22 0.03 1.97 19.32 21.50
